Imaging Pneumonia |
Normal lateral-Answers |
|||||||||||||
 |
||||||||||||||
 |
||||||||||||||
 |
||||||||||||||
 |
||||||||||||||
Lobes and Fissures-blue lines--right and left major fissues (oblique fissures), superimposed on lateral view red line--minor fissure (horizontal fissure) |
||||||||||||||
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
yellow--right upper lobe, inferior boundary at minor fissue, posterior boundary at major fissure pink--right middle lobe, upper boundary minor fissure, posterior boundary major fissure, overlying heart purple--right lower lobe, inferior to major fissure, upper portion extends high into chest posteriorly |
||||||||||||
Right lobes |
||||||||||||
Left lobes |
||||||||||||
orange--left upper lobe, inferior boundary at major fissure, lingula overlies heart on left green--left lower lobe, inferior to major fissure, upper portion extends high into chest posteriorly |
||||||||||||
 |
 |
|||||||||||
 |
 |
|||||||||||
 |
||||||||||||
 |
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
